Volvo L120H wheel loader hire

Volvo H-Series wheel loaders

H-Series wheel loaders are built with an industry-leading, strong frame, which, combined with the ideally-matched genuine Volvo drivetrain, achieves long-lasting performance. And with the help of a range of smart apps you can boost the efficiency of your operation from the comfort of the cab.

Versatile

Take on any application with the H-Series wheel loaders, equipped with the Torque Parallel (TP) linkage for ultimate versatility. Not only does the TP linkage offer high breakout, tilt in and lifting forces, it keeps the attachments parallel throughout the lifting range for exceptional load stability and easy bucket filling. Change tools in a matter of seconds with the Volvo attachment bracket.

More efficient

Achieve up to 20% greater fuel efficiency thanks to advanced features, such as Eco pedal and the new optional lock-up function. The lock-up feature eliminates losses in the torque converter by creating a direct drive between the engine and transmission, which work in harmony with the axles. To improve cycle times and fuel use, customize the lock-up engagement of your machine.

Cab comfort

Hard work has never felt so easy from the spacious of the Volvo cab, featuring your choice of comfortable operator seat, as well as ergonomic controls. Perform basic configurations using the information panel, and keep an eye on the operation with the Contronic display.

Load assist

Gain access to a set of smart apps and boost the efficiency of your operation with Load Assist, powered by the 12” Volvo Co-Pilot monitor.

Reliable

Built by Volvo, for Volvo, you can count on the proven design of the latest wheel loaders to meet the demands of tough job sites. Renowned for their reliability, the next-generation H-Series wheel loaders are built with an industry-leading, strong frame, which, combined with the ideally-matched genuine Volvo drivetrain, achieves long-lasting performance.

L120H
Tires 23.5R25 XHA2 L3			REHANDLING*													GENERAL PURPOSE																			ROCK**	LIGHT MATERIAL					LONG BOOM***
				3.8 m³ STE P BOE							3.8 m³ STE H BOE					3.3 m³ STE P T							3.3 m³ STE H T					3.6 m³ STE P BOE			3.6 m³ STE H BOE	3.0 m³ SPN P T SEG	5.5 m³ LM H			9.5 m³ LM H
Volume, heaped ISO/SAE	m³	3.8							3.8					3.3							3.3					3.6			3.6	3	5.5			9.5
Volume at 110% fill factor	m³	4.2							4.2					3.6							3.6					4.0			4.0	3.3	6.1			10.5
Static tipping load, straight	kg	15 660							14 960					14 800							14 450					14 810			14 080	14 860	13 010			13 120	-2 680
at 35° turn	kg	13 870							13 210					13 120							12 790					13 110			12 430	13 160	11 440			11 510	-2 440
at full turn	kg	13 340							12 700					12 630							12 300					12 610			11 950	12 660	10 980			11 040	-2 370
Breakout force	kN	162.4							151.8					189.2							173.5					172.9			159.6	150.6	121.6			106.0
A	mm	8 170							8 320					8 230							8 340					8 050			8 160	8 390	8 610			8 910	460
E	mm	1 250							1 400					1 380							1 480					1 230			1 330	1 520	1 730			1 990	-20
H	mm	2 890							2 770					2 780							2 700					2 900			2 830	2 690	2 480			2 270	560
L	mm	5 750							5 780					5 700							5 760					5 750			5 820	5 690	5 900			6 070	520
M	mm	1 250							1 330					1 310							1 390					1 190			1 280	1 440	1 560			1 760	-50
N	mm	1 850							1 860					1 840							1 880					1 800			1 840	1 930	1 890			1 910	450
V	mm	3 000							3 000					3 000							3 000					3 000			3 000	2 880	3 000			3 400
a₁ clearance circle	mm	13 040							13 090					12 890							12 950					12 800			12 850	12 890	13 130			13 660	410
Operating weight	kg	20 110							20 330					19 280							19 460					19 420			19 640	20 260	19 900			20 120	240
	* Measured with additional rehandling counterweight | ** With MICHELIN 23,5R25 XMINE D2 L5 Tire | *** Based on 3.0 m³ STE H T bucket
